Introduction

The Timing Antenna HX-TR201A is a cutting-edge solution engineered to deliver exceptional performance across a wide range of applications, including timing synchronization, mobile operations, precision navigation, and military-grade deployments. It boasts comprehensive signal support for GPS L1/L2, BDS B1C/B1I/B2I, GLONASS L1/L2, and GALILEO E1, ensuring robust compatibility with global satellite navigation systems. This versatility makes it an indispensable tool for industries requiring pinpoint accuracy and unwavering reliability.

Multi-Constellation Dual Band GNSS Support
Outstanding Signal-to-Noise Ratio
High LNA Gain with Strong Out-of-Band Rejection
Excellent Circular Polarization and Multipath Rejection
Extreme Cold Resistance (down to -55°C)
All-Weather Enclosure & Bird-Deterring Radome Design

Key Features

Multi-Constellation and Multi-Frequency GNSS Support

HX-TR201A supports GPS L1/L2, BDS B1C/B1I/B2I, GLONASS L1/L2 and GALILEO E1 signals, providing broad multi-constellation and multi-frequency GNSS coverage. With 360° azimuth coverage and up to 4.0dBi peak gain, it supports reliable signal reception for precision timing, synchronization and other high-reliability GNSS applications.
Superb Circular Polarization

Featuring a highly circular wideband patch element with RHCP polarization and an axial ratio of ≤3dB, HX-TR201A delivers consistent circular polarization across its supported frequencies. This design helps suppress reflected multipath signals and maintain cleaner, more reliable GNSS reception in challenging signal environments.
Outstanding Signal-to-Noise Ratio

Equipped with a high-performance Low Noise Amplifier, HX-TR201A provides 37±2dB LNA gain with a noise figure of ≤2dB. Combined with ±2dB passband ripple and ≤5ns group delay ripple, it helps preserve signal quality and supports stable, consistent performance for precision timing and synchronization systems.
Ideal for Harsh Environments

Designed for demanding outdoor installations, HX-TR201A operates from -55°C to +85°C and features IP69K/IP67 protection. It is also tested for vibration, shock, 96-hour salt fog and electrostatic discharge, while its conical radome helps discourage birds and shed accumulated ice or snow for reliable year-round operation.
