OEM GNSS Antenna JH002
For Interference Mitigation & High-Precision Positioning
Inquiry
Overview
Key Features
Parameters
Applications
Related Products
Overview
The JH002 is a dual-frequency OEM GNSS antenna with exceptional anti-interference performance, designed for challenging electromagnetic environments, including high-power and strong multipath scenarios. Its bottom-mounted vertical and horizontal polarization suppressors, coupled with advanced pre-multiple filtering, effectively suppress out-of-band noise and multipath signals, significantly enhancing anti-interference capabilities. It is ideal to be integrated into applications requiring both interference mitigation and high-precision positioning, such as portable or large mobile ground equipment and high-altitude drones. It also supports static millimeter-level positioning with multi-brand boards.
Key Features
Innovative Polarization Suppression Design
This antenna utilizes a ceramic stacked antenna as its primary structure, incorporating vertical and horizontal polarization suppressors at the base, which reduces the electromagnetic interference caused by the asymmetry of the mounting platform.
Strong Multipath Signal Suppression
The antenna is equipped with powerful polarization suppressors that can effectively mitigate unwanted left-hand circular polarization (LHCP) signals and non-line-of-sight signals, thereby enhancing anti-interference performance.
Superior Out-of-Band Signal Rejection
The antenna is equipped with advanced pre-multiple filters that effectively eliminate unwanted out-of-band interference signals, thereby reducing adjacent frequency signal interference.
expand-arrows (1).png
Ready-to-Integrate Structure
This antenna boasts a small form factor (Φ109mm*H134mm) and light weight (250g). It is IP67-rated, providing excellent water and dust protection, along with corrosion and shock resistance.
Parameters
ANTENNA PERFORMANCE
Frequency Coverage
GPS L1/L2; BDS B1
VSWR
≤1.5
Impedance
50Ω
Polarization
RHCP
Axial Ratio
≤3dB
Coverage Angle
Azimuth: 0-360°; Elevation: 0-90°
Peak Gain
3.5dBic@B1/L1; 2.5dBic@L2
CIRCUIT PERFORMANCE
LNA Gain
35±2dB
Out-of-Band Rejection
85dB@50MHz
Burnout Resistance
≥10W
Noise Figure
L1: ≤2.0 L2: ≤2.5
Group Delay
≤10ns
VSWR
≤2
Operation Voltage
5-12V
Operation Current
≤150mA
SYSTEM PERFORMANCE
Phase Center Error
≤3mm
Positioning Accuracy
Static millimeter level
Adaptation Board
Compatible with multi-brand boards, with some requiring
LNA gain adjustment
MECHANICAL
Dimensions
L80mm*W80mm*H16.6mm (Connectors not included)
Weight
≤75g
Mounting
M2.5 Screws Fixed
Connector
SMA Male
ENVIRONMENTAL
Operating Temperature
-40°~+70°
Storage Temperature
-45°~+85°
Quality Level
Industrial Grade
Product Certification
RoHS
Localization Rate
100%
