OEM GNSS Antenna HX-CSX078A
Embedded Full Frequency GNSS
Antenna with L-Band
Inquiry
Overview
Key Features
Parameters
Applications
Download
Related Products
Overview
Harxon HX-CSX078A is a precision tuned, stacked patch GNSS antenna that provides reliable and consistent positioning services across the full bandwidth of the antenna. Its superior positioning accuracy and powerful system compatibility makes it ideal to be integrated into various surveying and RTK applications.
Key Features
Consistent Performance Across Full Frequency Bands
HX-CSX078A offers full support for superior satellite signals tracking, including GPS, GLONASS, Galileo and BeiDou, as well as L-Band correction services. It offers a very stable phase center variation with advanced multipoint feeding technology.
Great Multipath Rejection and Powerful Anti-Interference Capacity
HX-CSX078A equips an anti-multipath intercepter and provides superior multi-path signal rejection. Besides, the pre-filtered LNA restraints unwanted electromagnetic interferences and significantly avoids signal loss.
Easy Integration Design for Various Applications
The unique structure design simplifies RTK integration, and minimizes the overall device dimension, optimizing the positioning efficiency and performance of system integrators.
Parameters
PERFORMANCE
Signal Received
GPS L1/L2/L5
GLONASS L1/L2/L3
GALILEO E1/E5a/E5b/E6
BDS B1/B2/B3
QZSS L1/L2/L5/L6
IRNSS L5
SBAS L1/L5
L-Band
Nominal Impedance
50Ω
Polarization
RHCP
Axial Ratio
≤3dB
Azimuth Coverage
360°(omni-directional)
Output VSWR
≤2.0
Peak Gain
5.5dBi
LNA
LNA Gain
40±2dB
Noise Figure
≤2dB
Output VSWR
≤2.0
Passband Ripple
±2dB
Operation Voltage
+3.3 to +12VDC
Operation Current
≤45mA
Differential Propagation Delay
≤5ns
MECHANICAL
Dimensions
¢111x24.5mm
Connector
MCX-C-JW1.5
Weight
≤220g
ENVIRONMENTAL
Operating Temperature
-40℃ to +85℃
Storage Temperature
-55℃ to +85℃
Humidity
95% non-condensing
Applications
Download
Harxon HX-CSX078A Brochure
2022-04-06
Harxon HX-CSX078A Brochure
2022-04-22
