Timing Antenna HX-TR201A
GNSS Antenna for Timing
and Synchronisation Applications
Inquiry
Overview
Key Features
Parameters
Applications
Related Products
Overview
The Timing Antenna HX-TR201A is a cutting-edge solution engineered to deliver exceptional performance across a wide range of applications, including timing synchronization, mobile operations, precision navigation, and military-grade deployments. It boasts comprehensive signal support for GPS L1/L2, BDS B1C/B1I/B2I, GLONASS L1/L2, and GALILEO E1, ensuring robust
compatibility with global satellite navigation systems. This versatility makes it an indispensable tool for industries requiring pinpoint accuracy and unwavering reliability.
Key Features
Superb Circular Polarization
Designed with advanced technology, it features a highly circular wideband patch element paired with a state-of-the-art LNA. This powerful combination delivers a truly circular response across its entire bandwidth, setting a new standard for multipath signal rejection
Outstanding Signal-to-Noise Ratio
Its outstanding axial ratio remains consistent across all supported frequencies, guaranteeing uniform performance and enhanced signal integrity no matter the conditions
Ideal for Harsh Environments
This antenna operates flawlessly at temperatures as low as -55°C, making it a top choice for deployments in harsh climates or remote locations. The conical radome deters bird interference and efficiently shedding ice or snow to maintain optimal functionality year-round.
Parameters
PERFORMANCE
Signal Received
GPS L1/L2
BDS B1C/B1I/B2IC
GLONASS L1/L2
GALILEO E1
VSWR
≤2.0
Polarization
RHCP
Peak Gain
4.0dBic
Impedance
50 ohm
Azimuth Coverage
360°
Axial Ratio
≤3dB
Phase Centre Variation
±2mm
LNA
LNA Gain
37±3dB
Output VSWR
≤2.0
Passband Ripple
±2dB
Noise Figure
≤2dB
Operation Voltage
+3.3~+12VDC
Operation Current
≤45mA
Group Delay Ripple
≤5ns
MECHANICAL
Dimensions
Φ69×48.5mm
Weight
≤260g
Connector
N-K
Mount
Through-hole mounting with an M18 nut on a flat surface
ENVIRONMENTAL
Operating Temperature
-55℃~+85℃
Storage Temperature
-55℃~+85℃
Humidity
95% Non-condensing
Vibration
MIL-STD-810D Method 514.3-1
Vibration
MIL-STD-810D Method 514.3-1
Shock
MIL-STD-810G Method 516.6
Salt Fog
96H
EMC
(RF port electrostatic discharge)
Contact 8 kV, Air 15 kV, 10 times
IP Rating (housing)
IP69K/IP67
