Overview

The embedded GNSS antenna HX-CUX014A(L1+L5) is a high gain, low profile and compact active GNSS antenna that provides reliable and consistent positioning services for high dynamic applications such as UAV, small robots and autonomous vehicles. It features new structure, small size, high sensitivity and low power consumption.

Key Features

Consistent Performance Across Full Frequency Bands

HX-CUX014A(L1+L5) offers four support for superior satellite signals tracking, including GPS, GLONASS, Galileo and BeiDou. It offers a very stable phase center variation with advanced multipoint feeding technology

Strong Anti-interference Perfprmance

HX-CUX014A(L1+L5) is equipped with a robust pre-filtered LNA to minimize de-sensing from high level out-of-band signals, and restraints possible electromagnetic interferences for consistent and reliable GNSS signals.

Small Size, Light Weight, Low Power Consumption

HX-CUX014A(L1+L5) has a compact dimension of 64mm *64mm*13.4mm, weighing only 90g for low power consumption. The new structure design simplifies the integration and minimizes the overall machine dimension.

Parameters

PERFORMANCE

Signal Received

GPS L1/L5
GLONASS L1
GALILEO E1/E5a
BDS B1I/B1C/B2a

Nominal Impedance

50Ω

Polarization

RHCP

Axial Ratio

≤3dB

Azimuth Coverage

360°

Output VSWR

≤2.0

Peak Gain

1166-1278MHz 4dBi (@Zenith)
1520-1610MHz 4dBi (@Zenith)
L-band 3dBi (@Zenith)

LNA

LNA Gain

33±2dB

Noise Figure

≤2dB

Output VSWR

≤2.0

Group Delay Ripple

≤5ns

Operation Voltage

+3V ~ +12VDC

Operation Current

≤50mA

MECHANICAL

Dimensions

64mm*64mm*13.4mm

Connector

MMCX-JW

Weight

≤90g

ENVIRONMENTAL

Operating Temperature

-40℃ to +85℃

Storage Temperature

-55℃ to +85℃

Humidity

95% non-condensing
