Harxon Timing Antenna HX-CT3602A is a full GNSS band antenna ideal for any global GNSS time synchronization application. Its filtering design allows for wideband coverage while achieving superior out-of band rejection and high gain 28 dB performance. The small, conical design minimizes perching and provides runoff.
Key Features
High Performance Timing Antenna
HX-CT3602A supports GPS, GLONASS and GALILEO. It’s especially designed for timing, mobile, precision and military applications. It can produce superior multipath signal rejection.
Reliable and Consistent Signal Tracking
This antenna features a highly circular wideband patch element with a high-performance Low Noise Amplifier. This configuration provides excellent axial ratio that is constant across the full frequency band.
Rugged Enclosure for Tough Environments
HX-CT3602A is housed in a permanent mount industrial-grade weatherproof enclosure and is available with a wide variety of connectors. This antenna is also customizable in radome.
Parameters
PERFORMANCE
Signal Received
GPS L1 BDS B1I/B1C GLONASS L1 GALILEO E1 QZSS L1
VSWR
≤2.0
Polarization
RHCP
Peak Gain
>3dBic
Impedance
50 ohm
Beam Width
60°
Axial Ratio
≤3dB max
Out-of-band Rejection
>60dB(f0±100MHz)
LNA
LNA Gain
28±3dB
Noise Figure
≤3.5dB max
Supply Voltage Range
2.7～9V
Supply Current
9±3mA
MECHANICAL
Dimensions
φ60*54mm
Weight
≤85g
Radome / Enclosure
PC
Connector
TNC Female
Mount
Screws Mount
Color
White (Black optional)
ENVIRONMENTAL
Operating Temperature
-60℃~+85℃
Storage Temperature
-60℃~+85℃
Mechanical Vibration
Sine sweep 1g (0-p), 10~55~10Hz each axis
IP Rating (housing)
IP67
Applications
