Ruggedized Antenna HX-CVX606A
Reliable and Ruggedized with
Millimeter Accuracy
Inquiry
Overview
Key Features
Parameters
Applications
Download
Related Products
Overview
Harxon HX-CVX606A GNSS antenna is built into ruggedized enclosure with metal base, which allows the antenna to be used in high shock and vibration conditions. HX-CVX606A can provide millimeter level accuracy with strong anti-interference performance and stable phase center, ideal for surveying and I-construction applications.
Key Features
Ruggedized Enclosure for Tough Environments
HX-CVX606A is built into an independent aerodynamic enclosure with ruggedized metal base.The IP69K rating housing enables withstanding of high shock and vibration.
Consistent Performance Across Full Frequency Bands
HX-CVX606A offers full support for reliable and consistent satellite signals tracking. Additionally, it exhibits very stable phase center variation with advanced multipoint feeding technology and high gain with ultralow signal loss.
Tracking in Complex Environments
The high gain and wide beam width features ensure exceptional low elevation signal tracking performance, which make sure the antenna receives reliable and consistent signals even under harsh environment where blockage exists.
Strong Anti-interference Performance
The advanced LNA (Low Noise Amplifier) of the antenna excels in improved signal filtering and out-of-band rejection by restraining unwanted electromagnetic interferences.
Parameters
PERFORMANCE
Signal Received
Upper Band 1.525 to 1.615 GHz
Lower Band 1.165 to 1.3GHz GHz
GPS L1/L2/L5
GLONASS L1/L2/L3
GALILEO E1/E5a/E5b/E6
BDS B1/B2/B3
QZSS L1/L2/L5/L6
IRNSS L5
SBAS L1/L5
L-Band
Nominal Impedance
50Ω
Polarization
RHCP
Axial Ratio
≤3dB
Azimuth Coverage
360°
Output VSWR
≤2.0
Peak Gain
5.5dBi
LNA
LNA Gain
40±2dB
Noise Figure
≤2dB
Output VSWR
≤2.0
Passband Ripple
±2dB
Operation Voltage
+3.3 to +18VDC
Operation Current
≤45mA
Differential Propagation Delay
≤5ns
MECHANICAL
Dimensions
¢150×57.3mm
Connector
TNC-K
Weight
≤800g
Mounting
Pole Mount: Coarse threaded 5/8"-11, thread hole depth 14-18mm; Screws Mount: M8 screws
ENVIRONMENTAL
Operating Temperature
-50℃ to +85℃
Storage Temperature
-55℃ to +85℃
Humidity
95% non-condensing
Ingress Protection Rating
IP67, IP69K
Salt Spray
96h
Vibration
9.8gRMS,24-2000Hz
Shock
3 vertical axis 75Gs, 6ms
EMC (RF Input Static)
Connected: 8KV, Air: 15KV, 10 times
Regulatory Compliance
CE FCC ROHS
Applications
Download
Harxon HX-CVX606A Brochure
2022-08-04
